• 7-bit LED digits display
• Two serial port(RS232+RS232/485), support MODBUS-RTU
• Option:

       – LAN port(EtherNet/IP) ,support TCP,UDP,MODBUS-TCP
– 4-20mA x1 or 4-20mA x2, 16-bit resolution DAC
– PROFIBUS-DP
– CC-link
– PROFIENT, two LAN port(switch integrated inside ), support  (SR)NAP S2 and MRP
– EtherNet/IP, two LAN port(switch integrated inside )
– EtherCAT, two LAN port(switch integrated inside )
– CC LINK IE FB, two LAN port(switch integrated inside )

• I/O Option:

      – IN x8 / OC OUT x12
– IN x8 / Relay OUT x12

• PROFINET certificated by PI Association(Siemens PROFINET organization)
• OIML and CE certificated
• 6000e OIML W&M Approved, High precision ADC support 7500e
• Power supply: 220VAC/110VAC or 24VDC
• Housing:

      – Panel mount – IP65
